Description
Overview:
This Corteco oil shaft seal is a crankshaft seal for Iveco heavy-duty engines at the transmission end. Made from MVQ (silicone elastomer) in a durable red/orange finish, it is designed to maintain a clean, leak-free interface between the crankshaft and housing in demanding service. The size is 130 x 160 x 14 mm (5.12 x 6.30 x 0.55 inches), suitable for many Iveco applications found in construction, on-road haulage, and agricultural support machinery. The material provides flexibility and strong temperature resistance, helping the seal maintain contact under thermal cycling and vibration. Used across platforms such as EuroStar and EuroTech MH, this RWDR-K7 type seal is a reliable replacement where the original dimensions and specification are required to keep engines running efficiently.
Key Features:
- MVQ (silicone elastomer) for flexibility and high temperature resistance in harsh operating environments
- Size: 130 x 160 x 14 mm (5.12 x 6.30 x 0.55 inches) to match OE fit on the crankshaft transmission side
- Helps prevent oil leaks and keeps dust and debris out of the engine and gearbox interface
- Stable sealing under vibration and thermal cycling typical of heavy vehicles and plant support trucks
- Suitable for engine-oil environments commonly found in Iveco drivelines
- Corteco quality for consistent lip geometry and long service life when fitted correctly
- Straightforward press-fit with appropriate seal drivers; no modifications required when replacing like-for-like
- Direct dimensional replacement for common Iveco references including 40102690
Typical Applications:
Used on Iveco engines in EuroStar, EuroTech, EuroTrakker and related LD/MP series vehicles operating in haulage, quarry, and construction support. Ideal for routine maintenance and engine rebuilds to restore crankshaft sealing at the transmission end, reduce oil loss, and protect clutches and gearboxes from contamination.
Also known as:
Radial shaft seal, simmerring, seal ring, crank seal, rear crank seal, rear main oil seal, oil lip seal, crankshaft end seal.
Fits Models:
190 E 39, 190 E 39 /P, 190 E 43, 190 E 43 /P, 190 E39 /FP, 190E39, 190E39/FP, 190E39/P, 190E39P, 190E43, 190E43/P, 190E43P, 260 E 35 Y/P, 260 E 35 Y/PT, 260 E 35 Y/TN, 260 E 39 Y, 260 E 39 Y/FP, 260 E 39 Y/FS, 260 E 39 Y/P, 260 E 43 Y, 260 E 43 Y/P, 260E35Y/P, 260E35Y/PT, 260E35Y/TN, 260E39Y, 260E39Y/FP, 260E39Y/FS, 260E39Y/P, 260E43Y, 260E43Y/P, 440 E 39 T, 440 E 39 T/FP-CT, 440 E 39 T/P, 440 E 39 TX/P, 440 E 43 T, 440 E 43 T/P, 440 E 43 TX/P, 440E39T, 440E39T/FP-CT, 440E39T/P, 440E39TX/P, 440E43T, 440E43T/P, 440E43TX/P, EuroStar, EuroTech MH, EuroTech MP, EuroTechMH, EuroTechMP, EuroTrakker, LD 190 E 39 FP, LD 190 E 39 P, LD 190 E 43, LD 190 E 43 FP, LD 190 E 43 P, LD 260 E 39 FP, LD 260 E 39 P, LD 260 E 43 FP, LD 260 E 43 Y/PS, LD 260 E 48 Y/PS, LD 440 E 39 T, LD 440 E 39 T/P, LD 440 E 39 TX, LD 440 E 39 TX/P, LD 440 E 43 T/P, LD 440 E 43 TX/P, LD 440 E 48 T/P, LD190E39FP, LD190E39P, LD190E43, LD190E43FP, LD190E43P, LD260E39FP, LD260E39P, LD260E43FP, LD260E43Y/PS, LD260E48Y/PS, LD440E39T, LD440E39T/P, LD440E39TX, LD440E39TX/P, LD440E43T/P, LD440E43TX/P, LD440E48T/P, MP 190 E 38 W Cursor, MP 190 E 44 W Cursor, MP 260 E 38 H Cursor, MP 260 E 38 W Cursor, MP 260 E 44 H Cursor, MP 260 E 44 W Cursor, MP 340 E 38 H Cursor, MP 340 E 38 HB Cursor, MP 340 E 44 H Cursor, MP 340 E 44 HB Cursor, MP 380 E 38 H Cursor, MP 380 E 38 HB Cursor, MP 380 E 38 W Cursor, MP 380 E 44 H Cursor, MP 380 E 44 HB Cursor, MP 380 E 44 W Cursor, MP 410 E 38 H Cursor, MP 410 E 38 HB Cursor, MP 410 E 44 H Cursor, MP 410 E 44 HB Cursor, MP 440 E 38 HT Cursor, MP 440 E 44 HT Cursor, MP 720 E 38 HT Cursor, MP 720 E 44 HT Cursor, MP 720 E 48 HT Cursor, MP190E38WCursor, MP190E44WCursor, MP260E38HCursor, MP260E38WCursor, MP260E44HCursor, MP260E44WCursor, MP340E38HBCursor, MP340E38HCursor, MP340E44HBCursor, MP340E44HCursor, MP380E38HBCursor, MP380E38HCursor, MP380E38WCursor, MP380E44HBCursor, MP380E44HCursor, MP380E44WCursor, MP410E38HBCursor, MP410E38HCursor, MP410E44HBCursor, MP410E44HCursor, MP440E38HTCursor, MP440E44HTCursor, MP720E38HTCursor, MP720E44HTCursor, MP720E48HTCursor
Alternate Part Numbers:
82029820, 40102690, 454.05, 45405
Product Specifications
| L&S Part No. | 320 285 |
|---|---|
| Manufacturer | Corteco |
| OEM No. | 12029820B |
| Unit of Sale | 1 |
| Size | 130 x 160 x 14mm |
| Machine Type | Excavators, Tractors |
| Fits Brands | Elring, Iveco |
| Key Features | - MVQ silicone elastomer for flexibility and temperature resistance - Size: 130 x 160 x 14 mm for OE fit - Prevents oil leaks and blocks dust and debris - Suitable for Iveco engines in EuroStar, EuroTech, EuroTrakker - Direct replacement for part numbers 82029820, 40102690, 454.05 |
