Description
Overview:
This Genuine Husqvarna Pin Screw is an OEM fixing designed for heavy‐duty chainsaw assemblies on the 395 XP and 394XP. Manufactured from high‐strength steel for durability, it provides a secure, precise location and fastening point within the saw's chassis or cover assemblies, helping components stay aligned under vibration and load. Supplied to Husqvarna specification under part number 503 46 42-01 (MPN 503464201), it is a direct replacement for the original item and maintains the intended fit and function. Suitable for professional and demanding domestic use, it supports safe, consistent operation by keeping critical parts firmly in place. Use it when refurbishing, repairing, or carrying out routine maintenance where the parts diagram specifies this screw‐type locating pin.
Key Features:
- Genuine Husqvarna part for OEM fit, compatibility, and reliability
- High-strength steel construction resists wear, impact, and vibration
- Precision-machined threads and pin geometry for consistent seating
- Stable fastening helps maintain alignment of adjacent components
- Corrosion-resistant finish to support long service life in outdoor use
- Direct replacement for the original part; no modification required
- Suitable for regular professional workloads and frequent maintenance cycles
- Straightforward installation with standard workshop tools; refer to the service manual for torque and placement
Typical Applications:
Used wherever Husqvarna specifies a screw-type locating pin within the chainsaw assembly, such as fixing or aligning components on the body or covers. Ideal for replacing worn, damaged, or loosened fasteners to restore secure fit and maintain safe operation on hard‐working saws used in felling, bucking, and heavy site work.
Also known as:
Screw pin, locating pin fastener, guide pin screw, retention stud, assembly fixing, chainsaw locating fastener, OEM fixing for Husqvarna chainsaws.
Fits Models:
394XP, 395 XP, 395XP
Alternate Part Numbers:
503 46 42-01, 503464201
Product Specifications
| L&S Part No. | 503 46 42 01 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Husqvarna |
| OEM No. | 503464201 |
| Unit of Sale | 1 |
| Machine Type | Chainsaws |
| Fits Brands | Husqvarna |
| Key Features | - Genuine Husqvarna part ensures OEM fit and compatibility - High-strength steel resists wear and vibration - Precision-machined for consistent seating and alignment - Corrosion-resistant finish for outdoor durability - Fits Husqvarna 394XP and 395XP chainsaws |
| Fits Models | 394XP | 395XP |
