Description
Overview:
This longlife detachable Bowden cable for AL-KO old style brakes (MPN 211 031) is a replacement brake cable used on braked trailers and caravans fitted with AL-KO running gear. It features a protective sheath over the inner wire to reduce corrosion and wear in service. The cable has an outer (L1) length of 1620 mm and an inner (L) length of 1830 mm, making it suitable where these dimensions match the original installation. The bell at the backplate end is sized 26 mm external / 23.5 mm internal to suit AL-KO old style brake backplates. Typical applications include general duty goods trailers, plant and equipment transporters, boat trailers and caravans using an overrun braking system. The detachable design supports easier removal and refitting during brake maintenance, helping to keep downtime low while maintaining positive, consistent brake actuation.
Key Features:
- Long life detachable Bowden cable suitable for AL-KO old style brakes
- Outer length (L1): 1620 mm (1.62 m / approx. 63.8 in)
- Inner length (L): 1830 mm (1.83 m / approx. 72.0 in)
- Bell size: 26 mm external (approx. 1.02 in) / 23.5 mm internal (approx. 0.93 in)
- Sheathed inner cable to protect against rust and abrasion
- Detachable design to aid installation, adjustment and replacement
- Robust construction for frequent use on braked trailer running gear
- Compatible with AL-KO old style brake backplates requiring 26/23.5 mm bell
- Maypole reference: MP41416
Typical Applications:
Used on braked trailers and caravans with AL-KO axles and old style brake backplates, linking the compensator/handbrake mechanism to the brake lever on the backplate. Suitable where the original cable specifications match 1620 mm outer (L1), 1830 mm inner (L) and a 26 mm external / 23.5 mm internal bell. Common on goods trailers, plant/transport trailers and similar towing setups using AL-KO overrun braking systems.
Also known as:
- AL-KO Longlife Detachable Brake Cable 1620 mm L1
- Trailer Handbrake Cable 1620/1830 mm
- Bowden Cable for AL-KO Old Style Backplates
- Maypole part number MP41416
Product Specifications
| L&S Part No. | 211 031 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
