Description
Overview:
Rotalock Shoot Bolt, Medium Duty, Weld-On, Pin Ø25.5 mm, 14 mm Stroke (MPN 800 1079) is a compact, weld-on securing bolt designed for repeated locking and locating of doors, hatches and gates on working equipment. It is manufactured from mild steel and supplied with a zinc plated, clear passivated finish to help resist corrosion in service. A grease nipple is provided to allow routine lubrication and maintain a smooth action in harsh environments. The mechanism drives a Ø25.5 mm pin (approx. 1.00 in) with a 14 mm stroke (approx. 0.55 in) to positively engage into a keeper or frame. The body measures Ø35 mm (approx. 1.38 in) by 76 mm long (approx. 3.0 in), making it suitable for confined mounting locations on commercial vehicles, trailers, skips, balers, agricultural and general machinery.
Key Features:
- Medium duty Rotalock mechanism for positive, repeatable engagement
- Weld-on type for permanent installation to steel fabrications
- Mild steel construction for durability in fleet and plant environments
- Zinc plated, clear passivated finish for corrosion protection
- Integrated grease nipple for in-service lubrication and smooth operation
- Pin diameter: Ø25.5 mm (approx. 1.00 in)
- Stroke: 14 mm (approx. 0.55 in)
- Body length: 76 mm (approx. 3.0 in)
- Body diameter: Ø35 mm (approx. 1.38 in)
- Suitable for use on commercial vehicles, skips, balers, agricultural and general machinery
- Brand: Albert Jagger
Typical Applications:
Used to secure and locate side doors, rear doors, tailgates, lids and access panels on commercial vehicles and trailers. Common on plant transport bodies, van doors, agricultural equipment, skips and balers where a compact, greasable shoot bolt is required for reliable retention and quick release in daily service.
Also known as:
Spring bolt; Plunger latch; Rotary bolt; Locking pin; Door retaining bolt
Product Specifications
| L&S Part No. | 800 1079 |
|---|---|
| Unit of Sale | 1 |
