Description
Overview:
This overcentre latch (MPN 763 020) is a compact fastening catch for securing panels, lids and doors on trailer and vehicle bodywork. It uses a positive over-centre action to draw mating parts together and hold them closed under vibration. The latch has a zinc plated finish to provide corrosion resistance in outdoor and road-going environments. Key drawing dimensions are A = 126 mm (4.96 in), B = R3.5 mm (0.14 in), with two fixing holes Ø 5 mm (0.20 in), and dimension D = 30 mm (1.18 in). The unit carries a 280 kg (approx. 617 lb) rating, making it suitable for light to medium duty closures on commercial bodies and trailers. It is suitable for use with Maypole companion parts MP81301B and MP81302B to complete the latch-and-catch assembly on dropsides, tailgates, lockers and access doors.
Key Features:
- Overcentre latch for trailer and vehicle body closures
- Zinc plated finish for corrosion resistance
- Load rating: 280 kg (approx. 617 lb)
- Dimension A: 126 mm (4.96 in)
- Dimension B: R3.5 mm (0.14 in)
- Dimension D: 30 mm (1.18 in)
- Fixing: 2 x 5 mm (0.20 in) mounting holes
- Suitable for use with Maypole MP81301B and MP81302B components
Typical Applications:
Used on trailer bodies and plant transport equipment for securing tailgates, dropside boards, lockers, compartments and canopy doors. Common on general-purpose trailers, service bodies and utility builds where a compact, reliable toggle-style latch is required. Pairs with Maypole MP81301B or MP81302B components to complete the latch and keeper arrangement.
Also known as:
Overcentre catch
Toggle latch
Draw latch
Over-centre fastener
Maypole part number MP81402B
Product Specifications
| L&S Part No. | 763 020 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
| Key Features | - Zinc plated for corrosion resistance in outdoor environments - 280 kg load rating for light to medium duty closures - Dimension A: 126 mm, B: R3.5 mm, D: 30 mm - Two 5 mm mounting holes for secure installation - Compatible with Maypole MP81301B and MP81302B components |
