Description
Overview:
This over centre latch (MPN 763 059) is a robust toggle fastener used to secure panels, doors and lids on trailers, plant transport and general vehicle bodywork. It features a zinc-plated finish for corrosion resistance in outdoor and workshop environments. The latch provides a positive over-centre action to hold closures firmly and resist vibration during transport. Key drawing dimensions are: A = 142 mm (5.59 in), B = 21 mm (0.83 in), D = 35 mm (1.38 in), with two 5 mm (0.20 in) fixing holes. The stated capacity is 609 kg (approximately 1,343 lb), making it suitable for medium-duty closures on dropsides, tailgates and service compartments. It is designed to work with the corresponding Maypole catch/striker plate MP81305B, and can be used for both replacements and new fabrications in fleet maintenance and body building.
Key Features:
- Over centre latch for secure clamping of body fittings and closures
- Zinc-plated finish for corrosion protection in service
- 609 kg stated capacity (approx. 1,343 lb)
- Dimension A: 142 mm (5.59 in)
- Dimension B: 21 mm (0.83 in)
- Two fixing holes, 5 mm diameter (0.20 in)
- Dimension D: 35 mm (1.38 in)
- Pairs with Maypole catch/striker plate MP81305B
- Suited to trailer, plant and general vehicle bodywork applications
Typical Applications:
Used on trailer dropsides, tailgates, ramps, lockers and access panels where a compact, positive-action latch is required. Common on plant transporters, utility trailers and general fabrications in body shops. Designed to suit the matching Maypole catch/striker plate MP81305B for a complete latch set, either as a replacement part or for new builds.
Also known as:
Over-centre catch
Toggle latch
Draw latch
Tension latch
Over centre fastener
Maypole part number MP81405B
Product Specifications
| L&S Part No. | 763 059 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
| Key Features | - Zinc-plated for corrosion resistance - 609 kg capacity for medium-duty closures - Dimensions: 142 x 21 mm - Two 5 mm diameter fixing holes - Compatible with Maypole catch MP81305B |
