Description
Overview:
This pair of trailer suspension units with integral hubs (MPN 211 019) provides a compact, independent suspension solution for light trailers. Each unit has a yellow zinc plated finish for corrosion protection and uses a long‐life polyurethane suspension element to provide damping and springing without a separate axle beam. The hubs are factory-fitted with taper roller bearings and carry 4 wheel studs on the Mini pattern 4 inch (101.6 mm) pitch circle diameter, accepting 8 inch (203 mm) and 10 inch (254 mm) trailer wheels. Installation is by bolt-on mounting using four M8 fixing holes per unit. The rated load is 250 kg across the pair, suitable for small utility, camping and box trailers and similar light transport tasks. Wheel studs use 3/8 inch (9.5 mm) UNF thread for standard conical wheel nuts. Service parts include replacement hubs, caps, studs, nuts and bearing kits for straightforward maintenance.
Key Features:
- Pair of bolt-on independent suspension units with integral hubs
- Load rating: 250 kg per pair
- 4-stud Mini pattern hub, 4 in (101.6 mm) PCD
- Suits 8 in (203 mm) and 10 in (254 mm) wheels
- Yellow zinc plated finish for corrosion resistance
- Long-life polyurethane suspension element
- Hubs fitted with taper roller bearings
- Wheel studs: 3/8 in (9.5 mm) UNF with conical nuts
- 4 x M8 mounting holes per unit
- Spares support: MP418 hub, MP418CB hub cap, MP4187B conical nut, MP4185B stud, MP4181 bearing kit (1 hub)
Typical Applications:
Used on light, unbraked trailers where a compact, bolt-on suspension and hub assembly is required, including small box trailers, camping/utility trailers, trailer tents, garden trailers and lightweight equipment carriers. Compatible with Mini-pattern 4-stud wheels in 8 in and 10 in sizes. Suitable for new trailer builds, axle conversions or repair and replacement of existing suspension units using the same mounting format.
Also known as:
- Independent trailer suspension units with hubs, Mini 4-stud
- 4 in PCD suspension hub units for 8"/10" wheels
- 250 kg trailer suspension and hub pair
- Maypole part number MP206
Product Specifications
| L&S Part No. | 211 019 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
