Description
Overview:
Main trailer lighting harness with an 8-pin front plug and pre-terminated rear connections for Fristom lamps. The 6m loom includes two 6-pin Fristom quick-connect (bayonet) connectors for left and right lamps, plus two female 2-pin Superseal leads for number plate or marker feeds. The Superseal tails are 400mm long and are taken from the rear of the bayonet connectors. Suitable for use with Fristom rear lamps that use the 6-pin quick-connect system. Manufactured by Maypole.
Specification:
- 8-pin plug
- 6 m overall cable length
- 2 x 6-pin Fristom quick-connect (bayonet) lamp connectors
- 2 x 2-pin female Superseal leads for number plate/marker feeds
- 400 mm length for each Superseal lead
- Compatible with Fristom lamps using the 6-pin quick-connect system
- Manufacturer: Maypole
- Part number: MP77906
Typical Applications:
Main rear lighting loom on braked and unbraked trailers, plant and equipment transporters, and general-duty trailers fitted with Fristom 6-pin quick-connect rear lamps, providing lamp and number plate/marker light feeds.
Product Specifications
| L&S Part No. | 764 081 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
| Key Features | - 8-pin plug for main trailer lighting - 6 m overall cable length - 2 x 6-pin Fristom quick-connect lamp connectors - 2 x 2-pin female Superseal leads, 400 mm each - Compatible with Fristom 6-pin quick-connect lamps |
