Description
Overview:
This bell crank is a small linkage lever for the Dellorto FHCD 20/16A carburettor used on Villiers C30-series engines. It transfers throttle movement accurately to the carburettor spindle, helping the engine to idle, accelerate and run consistently. The part is made from solid brass for long service life and stable operation in outdoor conditions. It is a Genuine Villiers part (OEM No. 32565) and suits C30 and C30/2 engines that use the FHCD 20/16A carb. Dimensions are compact for correct clearance and fit: brass height 8.9 mm and wings thickness 1.5 mm. Supplied as unused old stock, so minor tarnish from storage is possible, but the part remains unused and fully serviceable for repairs or restorations.
Key Features:
- Genuine Villiers part, OEM No. 32565, for correct fit and function
- Brass construction resists corrosion and wear in damp, dusty environments
- Precise dimensions (8.9 mm height; 1.5 mm wing thickness) for reliable linkage alignment
- Designed for Dellorto FHCD 20/16A carburettor used on Villiers C30-series engines
- Stable throttle control helps maintain smooth idle and clean acceleration
- All-metal part with no plastic to deform under heat or fuel exposure
- Straightforward replacement using existing linkage hardware (no modifications expected)
- Suitable for workshop rebuilds and field repairs on vintage equipment
- Unused old stock: may show cosmetic ageing, with no effect on performance
Typical Applications:
Used to restore or maintain the throttle linkage on Villiers C30-series engines fitted with Dellorto FHCD 20/16A carburettors. Common in garden and light construction machinery, small stationary engines, and vintage horticultural equipment. Ideal for engine rebuilds, carburettor servicing, and resolving erratic throttle response or poor return-to-idle caused by worn or bent linkage parts.
Also known as:
Carburettor bell crank, throttle bellcrank, bell crank lever, carburettor linkage arm, throttle linkage lever, accelerator lever, Dellorto FHCD bell crank, Villiers carb linkage.
Fits Models:
C30, C30/2, C302, FHCD 20/16A
Product Specifications
| L&S Part No. | 32565 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
| Applications | C30, C30/2, C302, FHCD 20/16A |
| Machine Type | Engines |
| Fits Brands | Villiers |
| Fits Models | C30 |
