Description
Overview:
The Bevel Clamp DW777 is a genuine DeWalt replacement part designed to lock and hold the bevel angle on compatible DeWalt mitre saws. Built for everyday site and workshop use, it features a robust metal clamp body with a durable polymer hand knob that provides controlled tightening without slipping. This component keeps the saw's bevel setting secure for accurate, repeatable cuts, helping reduce drift and improving cut quality. Supplied under OEM No. 868680-00, it is an exact-fit service part for a wide range of DeWalt models, including the DW777 and DCS365. As a Genuine DeWalt Part, it offers reliable compatibility and consistent performance for tradespeople and DIY users who need dependable angle locking on their saws.
Key Features:
- Genuine DeWalt Part for assured fit and function (OEM No. 868680-00)
- Strong metal construction with a hard-wearing tightening knob for positive clamping
- Helps restore factory-accurate bevel settings and reduces play over time
- Smooth, controlled action for secure locking and easy release
- Direct replacement that uses existing fixings on the saw for straightforward fitting
- Durable threads and a practical hand grip suited to regular site or workshop use
- Corrosion-resisting finish to support long service life in tough conditions
- Compatible with multiple DeWalt mitre saws used across carpentry, joinery, and general building
Typical Applications:
Securing the bevel angle on DeWalt mitre saws for accurate bevel and compound cuts in timber, sheet materials, trims, and mouldings. Ideal for replacing a worn, slipping, or damaged clamp to maintain accuracy in tasks such as second-fix carpentry, kitchen fitting, skirting, architraves, framing, decking, and on-site installation work.
Also known as:
Bevel lock lever, bevel clamp assembly, bevel locking knob, mitre saw bevel clamp, angle lock, tilt lock, locking handle, bevel lock assembly.
Fits Models:
DCS365, DCS777, DCS778, DW701, DW707, DW711, DW711Type4, DW711Type5, DW711Type6, DW770, DW771, DW777, DWS771, DWS773, DWS774, DWS777, DWS778
Product Specifications
| L&S Part No. | 868680-00 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | DeWalt/Black and Decker |
| OEM No. | 868680-00 |
| Unit of Sale | 1 |
| Applications | DCS365, DCS777, DCS778, DW701, DW707, DW711, DW711Type4, DW711Type5, DW711Type6, DW770, DW771, DW777, DWS771, DWS773, DWS774, DWS777, DWS778 |
| Machine Type | Mitre Saw |
| Fits Brands | Black & Decker, DeWalt |
| Fits Models | DCS365 Type 1 | DCS777 Type 1 | DCS778 | DCS778 Type 1 | DW701 Type 2 | DW707 Type 2 | DW711 Type 1 | DW711 Type 2 | DW711 Type 3 | DW711 Type 4 | DW711 Type 5 | DW711 Type 6 | DW770 Type 1 | DW770 Type 2 | DW771 Type 1 | DW771 Type 2 | DW777 Type 1 | DW777 Type 2 | DWS771 | DWS771 Type 1 | DWS773 | DWS773 Type 1 | DWS774 | DWS774 Type 1 | DWS777 | DWS777 Type 1 | DWS778 | DWS778 Type 1 | DWS778 Type 2 |
