Description
Overview:
The Diesel Fuel Flow Meter 1" BSP Inlet/Outlet with 3 Figure Display is a compact, inline measuring device for monitoring the flow of diesel and other thin viscosity liquids. Built with a durable, corrosion‐resistant housing and a non‐flammable measuring chamber, it provides dependable readings in busy workshop and site environments. A clear mechanical counter shows a resettable 3‐digit batch in litres, backed by a 6‐digit totalizer for cumulative tracking. With 1" BSP (25.4 mm) connections, it installs easily into transfer lines on diesel pumps, bowsers, static tanks, generators, and plant maintenance rigs. Designed for straightforward calibration and everyday use, it helps tradespeople and fleet operators track consumption accurately, support stock control, and reduce wastage during refuelling and fluid transfer tasks.
Key Features:
- 1" BSP (25.4 mm) inlet/outlet for secure, widely compatible connections
- Resettable 3‐figure batch display in litres for quick, on‐the‐spot tracking (up to 999 L per batch)
- 6‐digit totalizer for long‐term cumulative monitoring
- Mechanical display requires no power for operation and is easy to read
- Minimum operating flow of 20 L/min suits medium to higher flow diesel transfer pumps
- Maximum working pressure of 3.5 bar for dependable performance in typical refuelling systems
- Non‐flammable disc measuring chamber suitable for diesel, gas oil, kerosene and other thin liquids
- Straightforward calibration to maintain accuracy after installation or fluid changes
- Compact body with mounting hole centre spacings of 103 mm and 25 mm for flexible fitting
- Robust, corrosion‐resistant construction for workshop, yard, agricultural and site use
Typical Applications:
Inline metering on diesel transfer pumps, bowser and tank installations, generator refuelling lines, plant and agricultural machinery maintenance, fleet depots, and workshop fuel management. Suitable for monitoring diesel, gas oil and kerosene usage, logging batch fills, and auditing consumption on static tanks, mobile fuel trolleys, and service vans where reliable litre‐by‐litre measurement is required.
Also known as:
Diesel litre counter, inline fuel counter, batch totaliser, transfer pump meter, mechanical litre register, positive displacement flow meter, in‐line diesel gauge, fuel line meter, litre counting gauge, mechanical flow counter.
Product Specifications
| L&S Part No. | 800 800 |
|---|---|
| Unit of Sale | 1 |
