Description
Overview:
The Hydraulic Filter 109 x 65mm is a spin‐on canister filter for cleaning hydraulic oil and protecting pumps, valves, and actuators in plant, agricultural, and garden machinery. It features a robust painted steel housing with a high‐efficiency filtration media to capture harmful particles and sludge. Sized at 109 mm x 65 mm (4.29 in x 2.56 in) with a 3/4" BSP thread (approx. 26.4 mm outside diameter), it is straightforward to fit where specified. This filter replaces OEM references such as Kubota 68191-62180 and JCB PP17755, and suits a wide range of systems that call for these equivalents. Commonly used on compact excavators and site dumpers, it also matches references PP17755 and T5730 used across many hydraulic applications.
Key Features:
- Compact 109 mm x 65 mm size (4.29 in x 2.56 in) for easy installation in tight bays
- 3/4" BSP thread (approx. 26.4 mm OD) for straightforward, secure mounting
- Robust steel canister for durability and resistance to vibration in harsh environments
- High‐efficiency media helps maintain clean hydraulic oil and stable system performance
- Supports reliable operation of pumps, spools, and cylinders by reducing wear
- Spin‐on format for quick changeovers and reduced downtime during servicing
- Widely cross‐referenced to Kubota and JCB numbers for easier sourcing and compatibility checks
- Suitable for return‐line filtration where specified by the machine manufacturer
- Helps extend service intervals and component life by controlling contamination
- Quality construction aimed at consistent flow and filtration under typical operating pressures
Typical Applications:
General hydraulic oil filtration on compact excavators, site dumpers, compact tractors, loaders, telehandlers, and hydraulic power packs. Often used on return lines or dedicated filter heads to protect sensitive components, maintain smooth control, and reduce premature wear in construction, landscaping, groundcare, and light industrial equipment.
Also known as:
Hydraulic oil filter, spin‐on hydraulic filter, return‐line filter canister, hydraulic filter cartridge, replacement hydraulic element, oil filter canister, spin‐on cartridge.
Fits Models:
PP17755, T5730, D 150 RM, D 150 RMA, D 150 RMG x4, KX41-2, KX41H, D150RM, D150RMA, D150RMGX4, KX412
Alternate Part Numbers:
MSZ2010MCVB10, HYDAC1251205, SP64A34GR125, OMTSF64A34GO, FS120B4T125, ZINGASS0700, FIN-FH50674, 68191.62180, 69721.62180, MSZ201MNXB4, FUC-SE1320, LHA 834100, 6819162180, FINFH50674, MSZ2010MNB, SE75221110, SF HY18564, X250903206, UC.SE.1320, 6972162180, FST1071R0, SS1B2A1AP, UCCSE1320, LHA834100, SFHY18564
Product Specifications
| L&S Part No. | LH7201 |
|---|---|
| OEM No. | H1944 |
| Unit of Sale | 1 |
| Size | 109mm x 65mm x 65mm x 3/4" BSP Thread |
| Applications | PP17755, T5730, D 150 RM, D 150 RMA, D 150 RMG x4, KX41-2, KX41H, D150RM, D150RMA, D150RMGX4, KX412 |
| Machine Type | Excavators |
| Fits Brands | Ausa, Benford, JCB, Kubota, Thwaites |
