Description
Overview:
The Hydraulic Filter, Spin On (116 x 95mm) replaces Baldwin B328 and is a Genuine OEM part. This filter is responsible for cleaning hydraulic fluid, removing contaminants to protect system components. It is located within the hydraulic system of the PT9000 model, filtering fluid between the pump and actuators to ensure smooth operation.
Key Features:
- Diameter: 116mm
- Height: 95mm
- Spin on filter type
- Genuine replacement for Baldwin B328
- Compatible with PT9000 model
Typical Applications:
Used in hydraulic systems to maintain fluid purity and component function. Essential in preventing particulate damage in high-pressure environments.
Also known as:
Hydraulic fluid filter, Spin-on hydraulic filter, Baldwin B328 equivalent
Fits Models:
PT9000
Alternate Part Numbers:
EM 230-149M5, 11993686-2, 1006763059, XKCF-00646, 1551000700, WGH6337, SPH9676, SH 60243, BT344-S, 2609688, SH8260, H1618, 2161
Product Specifications
| L&S Part No. | LH7637 |
|---|---|
| Part Type | Non Genuine Part |
| Unit of Sale | 1 |
| Size | Size: 120mm x 100mm x 90mm x Thread: 13/16-16 UNF |
| Fits Brands | Baldwin, Crosland, Fleetguard, Greyfriars, Iveco, Kalmar Climax, Massey Ferguson, Purolator, Schuup, Woodgate |
| Key Features | - Spin-on hydraulic filter measures 116 x 95mm. - Replaces Baldwin filter model B328. - Compatible with PT9000 machines. - Includes many OEM part number alternatives. - Genuine OEM part classification. |
| Filter Specifications | D1: 97mm D2: 94mm D3: 72mm H1: 113mm H2: 110mm H3: 9mm Thread: 13/16"-16UN By-pass valve: 1 |
| Fits Models | PT9000 |
