Description
Overview:
The Mechanical Suspension Seat MGV35 With Belt by United Seats is a heavy‐duty operator seat for site dumpers and similar machinery. Finished in durable black PVC trim, it is built to handle tough, muddy, and wet conditions while remaining easy to clean. The mechanical suspension system supports operator comfort with a weight setting from 50-150 kg (110-330 lbs) and 80 mm (3.15 inches) of suspension travel to reduce jolts. A foldable, adjustable backrest helps tailor the driving position, and an integrated seat belt and contact switch support safety systems. Fore-aft positioning is simple using slide rails with 180 mm (7.09 inches) of travel, set on 328 mm (12.91 inches) centres for stable mounting. Typical uses include Thwaites and JCB dumpers where a compact, reliable seat is required.
Key Features:
- Mechanical suspension with 50-150 kg (110-330 lbs) weight adjustment for the correct damping by operator
- 80 mm (3.15 inches) suspension travel to absorb shocks and vibration on rough ground
- 180 mm (7.09 inches) slide travel for accurate fore-aft positioning
- Slide rails on 328 mm (12.91 inches) centres for secure installation on compatible bases
- Foldable, adjustable backrest to fine‐tune posture and allow easier cab access
- Integrated seat belt and contact (operator‐presence) switch to support machine safety interlocks
- Heavy‐duty black PVC trim resists wear, dirt, and moisture; simple wipe‐clean maintenance
- Seat width 460 mm (18.11 inches); overall height about 640 mm (25.20 inches) for good support in compact cabs
- Robust build for frequent, long‐hour use in construction and grounds‐maintenance environments
- Mechanical design requires no compressor or air supply, reducing maintenance and complexity
- Smooth slide operation for quick driver changeovers on multi‐user machines
Typical Applications:
Replacement or upgrade seat for site dumpers and similar plant. Commonly specified on Thwaites 6 to 10 dumpers, cabbed dumpers, Mecalac dumpers, and JCB dumpers. Suitable where a compact, belt‐equipped mechanical suspension seat is needed to improve comfort, reduce fatigue, and maintain operator presence functionality during extended shifts in quarry, site, and yard work.
Also known as:
Dumper driver seat with belt, plant suspension seat, operator‐presence suspension seat, site dumper seat assembly, mechanical suspension operator seat, compact machinery seat with belt, adjustable suspension driver seat, plant machinery seating.
Product Specifications
| L&S Part No. | 084 235 |
|---|---|
| Manufacturer | United Seats |
| Unit of Sale | 1 |
| Machine Type | Dumpers |
