Description
Overview:
The Locating Pin for Kohler KT600 and KT610 engines is a genuine Kohler component engineered to keep engine parts precisely aligned during assembly and operation. Made from robust metal (steel), it helps maintain correct positioning between mating parts such as crankcase halves, covers and housings, which supports smooth running and reduces wear. Its close tolerances provide a snug fit to minimise play and vibration, helping to protect engine integrity over time. This pin is suitable for a wide range of Kohler petrol engines used in garden and construction machinery, including ride-on mowers, compact tractors, pressure washers and generators. It serves as a direct replacement for OEM No. 24 380 16-S, making it a reliable choice for routine servicing, rebuilds and preventative maintenance.
Key Features:
- Genuine Kohler part for assured fit and compatibility
- Direct replacement for OEM No. 24 380 16-S
- Durable steel construction for long service life
- Precision-machined to maintain accurate component alignment
- Helps reduce vibration, wear and premature gasket failure
- Clean, chamfered ends for easier insertion during assembly
- Corrosion-resistant finish for reliability in harsh environments
- Stable location of housings and covers to aid consistent rebuilds
- Suitable for a wide range of Kohler CH, CV, ECH, ECV, KT, LH, LV, SV and ZT series engines
- Simple to fit, supporting quick maintenance and reduced downtime
Typical Applications:
Used during engine assembly and service to align crankcases, sumps, timing covers and ancillary housings on Kohler engines. Ideal for overhauls, gasket replacement and routine maintenance on garden tractors, zero-turn mowers, commercial turf equipment and light construction machinery where accurate alignment is critical to sealing and smooth operation.
Also known as:
Locating dowel, dowel pin, location pin, guide pin, alignment dowel, register pin, engine locating dowel, positioning pin for Kohler engines.
Fits Models:
CH1000, CH11, CH18, CH20, CH22, CH23, CH25, CH26, CH410, CH430, CH450, CH620, CH640, CH640LP, CH670, CH680, CH682, CH730, CH730LP, CH732, CH735, CH740, CH740LP/NG, CH742, CH745, CH750, CH752, CH940, CH960, CH980, CV1000, CV14, CV17, CV18, CV20, CV22, CV23, CV25, CV26, CV430, CV450, CV460, CV461, CV490, CV491, CV492, CV493, CV620, CV624, CV640, CV670, CV675, CV680, CV682, CV725, CV730, CV732, CV740, CV742, CV745, CV750, CV752, CV940, CV960, CV980, ECH630, ECH650, ECH680, ECH730, ECH740, ECH749, ECH940, ECH980, ECV630, ECV650, ECV680, ECV730, ECV740, ECV749, ECV850, ECV860, ECV870, ECV880, ECV940, ECV980, EKT740, EKT750, ELH775, EZT715, EZT725, EZT740, EZT750, FCV740, KT600, KT610, KT620, KT715, KT725, KT730, KT735, KT740, KT745, LH630, LH640, LH685, LH690, LH750, LH755, LH775, LV625, LV675, LV680, PCH680, PCH740, PCV680, PCV740, PCV850, PCV860, SV710, SV715, SV720, SV725, SV730, SV735, SV740, SV810, SV820, SV830, SV840, ZT710, ZT720, ZT730, ZT740
Alternate Part Numbers:
24 380 16S, 2438016-S, 2438016S
Product Specifications
| L&S Part No. | 24 380 16-S |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Kohler |
| Unit of Sale | 1 |
| Applications | CH1000, CH11, CH18, CH20, CH22, CH23, CH25, CH26, CH410, CH430, CH450, CH620, CH640, CH640LP, CH670, CH680, CH682, CH730, CH730LP, CH732, CH735, CH740, CH740LP/NG, CH742, CH745, CH750, CH752, CH940, CH960, CH980, CV1000, CV14, CV17, CV18, CV20, CV22, CV23, CV25, CV26, CV430, CV450, CV460, CV461, CV490, CV491, CV492, CV493, CV620, CV624, CV640, CV670, CV675, CV680, CV682, CV725, CV730, CV732, CV740, CV742, CV745, CV750, CV752, CV940, CV960, CV980, ECH630, ECH650, ECH680, ECH730, ECH740, ECH749, ECH940, ECH980, ECV630, ECV650, ECV680, ECV730, ECV740, ECV749, ECV850, ECV860, ECV870, ECV880, ECV940, ECV980, EKT740, EKT750, ELH775, EZT715, EZT725, EZT740, EZT750, FCV740, KT600, KT610, KT620, KT715, KT725, KT730, KT735, KT740, KT745, LH630, LH640, LH685, LH690, LH750, LH755, LH775, LV625, LV675, LV680, PCH680, PCH740, PCV680, PCV740, PCV850, PCV860, SV710, SV715, SV720, SV725, SV730, SV735, SV740, SV810, SV820, SV830, SV840, ZT710, ZT720, ZT730, ZT740 |
| Machine Type | Engines |
| Fits Brands | Kohler |
| Fits Models | KT600 | KT610 | KT620 | KT715 | KT725 | KT730 | KT735 | KT740 | KT745 | EKT740 | EKT750 | ELH775 | LH775 | LH630 | LH640 | LH685 | LH690 | LH750 | LH755 | LV625 | LV675 | LV680 | FCV740 | PCH680 | PCH740 | PCV680 | PCV740 | PCV850 | PCV860 | CH26 | CH735 | CH745 | ECH630 | ECH650 | ECH680 | ECH730 | ECH740 | ECH749 | ECH940 | ECH980 | CV26 | CV745 | ECV630 | ECV650 | ECV680 | ECV730 | ECV740 | ECV749 | ECV850 | ECV860 | ECV870 | ECV880 | ECV940 | ECV980 | CH640LP | CH730LP | CH740LP/NG | CH11 | CH410 | CH430 | CH450 | CV14 | CV430 | CV450 | CV460 | CV461 | CV490 | CV491 | CV492 | CV493 | CH18 | CH20 | CH22 | CH23 | CH25 | CH620 | CH640 | CH670 | CH680 | CH682 | CH730 | CH732 | CH740 | CH742 | CH750 | CH752 | CH940 | CH960 | CH980 | CH1000 | CV17 | CV18 | CV20 | CV22 | CV23 | CV25 | CV620 | CV624 | CV640 | CV670 | CV675 | CV680 | CV682 | CV725 | CV730 | CV732 | CV740 | CV742 | CV750 | CV752 | CV940 | CV960 | CV980 | CV1000 | ZT710 | ZT720 | ZT730 | ZT740 | EZT740 | EZT750 | EZT715 | EZT725 | SV710 | SV715 | SV720 | SV725 | SV730 | SV735 | SV740 | SV810 | SV820 | SV830 | SV840 |
