Description
Overview:
This Setting Gauge is a genuine Stihl OEM tool designed for precise setup and maintenance of a wide range of Stihl machines, including brushcutters such as the FS 120 and FS 300. Made from tough, wear‐resistant polymer, it provides a stable reference for making consistent adjustments as specified in the service manual. Use it to help calibrate operating settings so your equipment runs smoothly and reliably. The compact, flat form factor is easy to handle at the bench or on site, and it stores neatly in a toolbox. As an original Stihl part, it offers the correct geometry for dependable repeatability across supported models. Ideal for tradespeople, grounds teams, and DIY users who want accurate, time‐saving maintenance.
Key Features:
- Genuine Stihl part for assured fit and function
- Durable moulded construction for workshop and site use
- Helps achieve consistent, repeatable settings per Stihl procedures
- Supports accurate calibration to maintain peak performance
- Compatible with a broad range of Stihl brushcutters and handheld machines
- Compact, lightweight, and easy to stow in a tool roll
- Simple to use with clear reference faces and edges
- Reduces guesswork, helping prevent premature wear and poor running
- Suitable for regular servicing schedules and quick checks
- Stihl MPN: 4118 890 6400
Typical Applications:
Used during routine servicing and repairs to set and verify machine adjustments, such as control linkages and other setup points specified by Stihl. Helps restore correct operation after part replacement, cable changes, or general tune‐ups on brushcutters and related handheld equipment.
Also known as:
Adjustment gauge, setup gauge, service gauge, setting tool, tuning gauge, calibration tool, reference gauge.
Fits Models:
BG 72, BG 75, BG72, BG75, BR 340, BR 340 L, BR 380, BR 420, BR 420 C, BR340, BR340L, BR380, BR420, BR420C, FC 75, FC 85, FC75, FC85, FR 350, FR 3900, FR 450, FR 480, FR 480 C, FR 85, FR 85 T, FR350, FR3900, FR450, FR480, FR480C, FR85, FR85T, FS 120, FS 120 R, FS 160, FS 180, FS 200, FS 200 R, FS 240, FS 250, FS 250 R, FS 260, FS 300, FS 350, FS 380, FS 3900, FS 400, FS 450, FS 480, FS 72, FS 74, FS 75, FS 76, FS 80, FS 80 R, FS 85, FS 85 R, FS 85 RX, FS 85 T, FS120, FS120R, FS160, FS180, FS200, FS200R, FS240, FS250, FS250R, FS260, FS300, FS350, FS380, FS3900, FS400, FS450, FS480, FS72, FS74, FS75, FS76, FS80, FS80R, FS85, FS85R, FS85RX, FS85T, HS 72, HS 74, HS 75, HS 76, HS 80, HS 85, HS72, HS74, HS75, HS76, HS80, HS85, HT 70, HT 70 K, HT 75, HT70, HT70K, HT75, KA 120, KA 120 R, KA 250, KA 85 R, KA120, KA120R, KA250, KA85R, KM 85, KM85, KR 85, KR85, SR 340, SR 420, SR340, SR420, TS 510, TS 760, TS510, TS760
Alternate Part Numbers:
4118-890-6400, 41188906400
Product Specifications
| L&S Part No. | 4118 890 6400 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Stihl |
| OEM No. | 41188906400 |
| Unit of Sale | 1 |
| Applications | BG 72, BG 75, BG72, BG75, BR 340, BR 340 L, BR 380, BR 420, BR 420 C, BR340, BR340L, BR380, BR420, BR420C, FC 75, FC 85, FC75, FC85, FR 350, FR 3900, FR 450, FR 480, FR 480 C, FR 85, FR 85 T, FR350, FR3900, FR450, FR480, FR480C, FR85, FR85T, FS 120, FS 120 R, FS 160, FS 180, FS 200, FS 200 R, FS 240, FS 250, FS 250 R, FS 260, FS 300, FS 350, FS 380, FS 3900, FS 400, FS 450, FS 480, FS 72, FS 74, FS 75, FS 76, FS 80, FS 80 R, FS 85, FS 85 R, FS 85 RX, FS 85 T, FS120, FS120R, FS160, FS180, FS200, FS200R, FS240, FS250, FS250R, FS260, FS300, FS350, FS380, FS3900, FS400, FS450, FS480, FS72, FS74, FS75, FS76, FS80, FS80R, FS85, FS85R, FS85RX, FS85T, HS 72, HS 74, HS 75, HS 76, HS 80, HS 85, HS72, HS74, HS75, HS76, HS80, HS85, HT 70, HT 70 K, HT 75, HT70, HT70K, HT75, KA 120, KA 120 R, KA 250, KA 85 R, KA120, KA120R, KA250, KA85R, KM 85, KM85, KR 85, KR85, SR 340, SR 420, SR340, SR420, TS 510, TS 760, TS510, TS760 |
| Machine Type | Brushcutters |
| Fits Brands | Stihl |
| Fits Models | FS75, FS80, FS85 | FS120, FS200, FS250 | FS240, FS260 | FS72, FS74, FS76 | FS3900 |
