Description
Overview:
This shear pin is a safety component for JET rope hoists rated at 1600 kg and 3200 kg. Made from durable steel, it is designed to fracture at a predetermined load to protect the hoist's internal mechanism from damage, helping to safeguard gear trains and drive components during overload events. The pin measures 30 mm (1.18 inches) in length and 7 mm (0.28 inches) in diameter, ensuring the correct fit and function in the specified hoists. It is identified by Manufacturer Part Number (MPN) 200 948 for accurate replacement. Suitable for routine maintenance and quick repairs, this pin helps keep lifting equipment operating safely and reliably on site, in workshops, and across general lifting and pulling tasks.
Key Features:
- Correct fit for JET 1600 kg/3200 kg rope hoists
- Steel construction for consistent and predictable shear performance
- Sacrificial design protects the hoist by failing under excessive load
- Dimensions: 30 mm (1.18 inches) length, 7 mm (0.28 inches) diameter
- Helps prevent costly damage to gears and drive components
- Straightforward to replace using basic hand tools
- Supports safe operation and reduces downtime in everyday use
- Precision-machined to specified dimensions for reliable seating and alignment
- Suitable for regular maintenance schedules and preventative servicing
- MPN 200 948 for easy identification and ordering
Typical Applications:
Used in JET wire rope hoists handling lifting and pulling on construction sites, in plant and workshop settings, facilities maintenance, agriculture, and utilities. Ideal where controlled overload protection is required to safeguard equipment, such as rigging tasks, load positioning, machinery installation, and general material handling.
Also known as:
Overload shear pin, sacrificial pin, fuse pin, torque‐limiter pin, safety shear link, overload protection pin for rope hoists.
Product Specifications
| L&S Part No. | 200 948 |
|---|---|
| Unit of Sale | 1 |
| Size | 7mm x 30mm |
| Machine Type | Winches |
