Description
Overview:
Jockey Wheel Spare 200 x 55mm, 20mm Bore, PU on Steel Rim - Maypole (MPN TR97435) is a replacement wheel and tyre assembly for jockey wheels and jockey legs. It has a 200mm diameter (approx. 8") and 55mm tread width (approx. 2.2"), with a polyurethane tyre on a steel rim. It fits the standard 20mm jockey wheel spindle; bore is quoted at 20.5mm (manufacturers quote 20-21mm interchangeably). Bore length is 68mm (approx. 2.7"). Maximum static load 500kg. Supplied as a wheel only, without spindle, bolt or fixings.
Specification:
- Wheel diameter: 200mm
- Tread width: 55mm
- Tyre: PU
- Rim: Steel
- Bore: 20.5mm
- Bore length: 68mm
- Maximum static load: 500kg
Fits These Jockey Wheels:
- 761 366 - 48mm Jockey Wheel Smooth 500kg (MP9721);
- 207 974 - 48mm Jockey Wheel Serrated 500kg (MP9724);
- 800 112 - 42mm Jockey Wheel 400kg (MP9723) - 2025-on production ONLY; pre-2025 MP9723 takes the 200 x 40mm wheel MP97236 instead;
- Also fits Maypole MP9720 and MP9722 (not stocked)
Also known as:
- Jockey wheel spare wheel
- Replacement jockey wheel wheel and tyre
- Nose wheel
- Trailer jack wheel
- Maypole MP97216
Product Specifications
| L&S Part No. | TR97435 |
|---|---|
| Key Features | - 200 mm diameter wheel with 55 mm tyre width - Polyurethane tyre with steel rim for durability - Bore size 20.5 mm diameter x 64 mm length - Supports up to 500 kg static load - Compatible with Maypole TR9741 and TR9743 assemblies |
