Description
Overview:
This Spline Screw M8 x 16 is a genuine Stihl fastener designed for reliable component fixing across Stihl and Stihl Viking lawn mowers and garden machinery. Made from robust steel with an internal spline drive, it provides positive engagement with the driver bit and helps prevent cam-out during tightening. The M8 thread (8 mm diameter) with a 16 mm length suits many factory locations where a compact, high‐strength fixing is required. It is commonly used on petrol models such as the Stihl Viking MB 248.1 and also on newer ranges like RM 248.0, helping keep brackets, guards and assemblies secure under vibration. OEM number 9025 313 5003 confirms fit and authenticity. Supplied as a Genuine Part for dependable maintenance and repair.
Key Features:
- Genuine Stihl Part for assured compatibility and performance (OEM 9025 313 5003)
- M8 x 16 mm size for compact, high‐strength fastening in multiple assemblies
- Internal spline drive for secure tool grip and reduced risk of cam‐out
- Steel construction for strength and long service life under vibration
- Accurate factory dimensions for repeatable torque and consistent clamp force
- Suitable for petrol, electric and battery mower platforms in the Stihl/Viking range
- Straightforward to fit and remove during routine servicing or part replacement
- Helps maintain safety and reliability by keeping components firmly fixed
Typical Applications:
Used to secure brackets, covers, handles, engine or deck hardware, and other structural parts on Stihl and Stihl Viking walk‐behind mowers. Ideal where a durable, vibration‐resistant fixing is needed in daily mowing conditions, from domestic lawns to commercial grounds maintenance.
Also known as:
M8 x 16 internal spline screw, star‐drive bolt, M8 machine screw, fixing screw, flange screw, metric spline fastener, M8 x 16 fixing.
Fits Models:
LB540
MB 248.1
MB 248.1 T
MB 248.2
MB 248.2 T
MB 248.3
MB 248.3 T
MB 248.4
MB 253.0
MB 253.0 T
MB 253.1
MB 253.1 T
ME 340
RL 540.0
RM 248.0
RM 248.0 T
RM 253.0
RM 253.0 T
RMA 339.0
RMA 339.0 C
Alternate Part Numbers:
9025-313-5003, 90253135003
Product Specifications
| L&S Part No. | 9025 313 5003 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Stihl |
| OEM No. | 90253135000 |
| Unit of Sale | 1 |
| Applications | LB540, MB 248.1, MB 248.1 T, MB 248.2, MB 248.2 T, MB 248.3, MB 248.3 T, MB 248.4, MB 253.0, MB 253.0 T, MB 253.1, MB 253.1 T, MB248.1, MB248.1T, MB248.2, MB248.2T, MB248.3, MB248.3T, MB248.4, MB2481, MB2481T, MB2482, MB2482T, MB2483, MB2483T, MB2484, MB253.0, MB253.0T, MB253.1, MB253.1T, MB2530, MB2530T, MB2531, MB2531T, ME 340, ME340, RL 540.0, RL540.0, RL5400, RM 248.0, RM 248.0 T, RM 253.0, RM 253.0 T, RM248.0, RM248.0T, RM2480, RM2480T, RM253.0, RM253.0T, RM2530, RM2530T, RMA 339.0, RMA 339.0 C, RMA339.0, RMA339.0C, RMA3390 |
| Machine Type | Mowers |
| Fits Brands | Stihl |
| Fits Models | RMA 339.0 | RMA 339.0 C | RM 248.0 | RM 248.0 T | RM 253.0 T | MB 248.4 | MB 248.3 T | MB 253.1 T | MB 248.1 | MB 248.2 | MB 248.3 | MB 248.1 T | MB 248.2 T | MB 253.0 | MB 253.1 | MB 253.0 T | ME 340 | RM 253.0 | RL 540.0 | ME 340 | ME 360 |
