Description
Overview:
The Tow Hitch Height Adjusting Bracket c/w Plate 370mm is a heavy‐duty, two‐pin assembly designed to set your towing point at the correct height on high‐clearance vehicles and plant. Built from robust black‐painted steel, it provides a stable, adjustable interface between the vehicle chassis and the coupling to help keep trailers level and controllable on uneven ground. Supplied complete with a back mounting plate and an outer plate for clamping, it uses 17.25 mm (0.68 inch) fixing holes sized for common M16 hardware. Dimensions include a 370 mm x 147 mm (14.57 inches x 5.79 inches) back plate and a 130 mm x 180 mm (5.12 inches x 7.09 inches) outer plate. Manufacturer Part Number (MPN): 883 598. Suitable for construction, agricultural and grounds‐care machinery.
Key Features:
- Heavy‐duty steel construction with a durable painted finish for outdoor use
- Two‐pin design for secure, positive retention of the hitch position
- Back mounting plate: 370 mm x 147 mm (14.57 inches x 5.79 inches) for wide chassis coverage
- Outer plate: 130 mm x 180 mm (5.12 inches x 7.09 inches) to clamp and locate the bracket
- Fixing holes: 17.25 mm (0.68 inches), sized for M16 bolts to simplify sourcing of hardware
- Helps align hitch height to trailer drawbar for stable towing on and off road
- Suited to high‐clearance vehicles used on sites, farms, estates and parks
- Simple bolt‐on installation; no welding required on compatible mounting faces
- Provides a rigid interface that resists twist and flex during towing
- MPN 883 598 for easy identification and parts matching
Typical Applications:
Setting or correcting tow height on compact tractors, ride‐on mowers, site dumpers, utility vehicles and similar plant. Useful for levelling yard trailers, small plant trailers and equipment carts to reduce nose‐up or nose‐down running. Ideal for landscaping, construction sites, grounds maintenance and agricultural tasks where terrain varies and reliable towing control is essential.
Also known as:
Adjustable towing bracket, two‐pin drawbar bracket, height‐adjust tow plate, drop/rise hitch plate, coupling height plate, tow bar height plate, adjustable trailer coupling plate, height setting bracket for tow hitch.
Product Specifications
| L&S Part No. | 883 598 |
|---|---|
| Unit of Sale | 1 |
| Size | 370mm |
| Machine Type | Tow Couplings |
