Description
Overview:
This Genuine Hamm elbow (OEM No. 1202510) is a factory-spec 90-degree connector used on Hamm twin drum rollers to route fluids or gases securely within the machine's system. Built from robust, high-quality metal for long service life, it helps maintain tight, leak-resistant connections in confined spaces around the engine bay and chassis. Designed for a direct fit on models such as the HD8 and HD10C (H170), it restores correct line routing and clearance, supporting reliable operation under vibration and heavy site use. Supplied as an exact replacement part, it fits without modification when installed in the manufacturer-specified location, making it suitable for routine maintenance and repairs on a wide range of Hamm rollers.
Key Features:
- Genuine Hamm Part for assured compatibility and performance (OEM 1202510)
- Precision 90-degree elbow for correct routing in tight spaces
- Durable metal construction for strength and resistance to wear and corrosion
- Direct replacement to restore sealed, leak-resistant joints
- Engineered to handle the operating demands of twin drum rollers
- Helps maintain correct hose/pipe alignment and component clearance
- Consistent fit and finish reduces installation time and downtime
- Suitable for the manufacturer-specified circuit on supported models
Typical Applications:
Used during scheduled servicing or repair when an elbow connector is worn, damaged, leaking, or distorted. Common in routing tasks where a 90-degree change of direction is required inside the roller's engine compartment or frame, helping maintain safe clearances from moving parts and heat sources. Ideal for restoring original performance and reliability in site conditions.
Also known as:
90-degree elbow, 90° bend, pipe elbow, hose elbow, angle connector, elbow fitting, bend connector, right-angle connector, union elbow.
Fits Models:
HD10-12, HD1012, HD10E-12E, HD10i-12i, HD13-14, HD1314, HD13i-14i, HD18-20, HD1820, HD30-35, HD3035, HD50, HD8-10C, HD810C
Product Specifications
| L&S Part No. | 1202510 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | HAMM |
| OEM No. | 1202510 |
| Unit of Sale | 1 |
| Applications | HD10-12, HD1012, HD10E-12E, HD10i-12i, HD13-14, HD1314, HD13i-14i, HD18-20, HD1820, HD30-35, HD3035, HD50, HD8-10C, HD810C |
| Machine Type | Rollers |
| Fits Models | HD8 - 10C (H170) Twin Drum Compaction Roller | HD13 - 14 (H172) Twin Drum Roller | HD10 - 12 (H171) Twin Drum Roller | HD10 - 12 (H230) | HD10 - 12 (H262) | HD10E - 12E (H289) | HD8 - 10C (H263) | HD30 - 35 (H247) | HD30 -35 (H286) | HD50 (H290) | HD50 (H295) | HD10i - 12i (H251) | HD13i - 14i (H231) | HD18 - 20 (H292) | HD18 - 20 (H293) |
