Description
Overview:
The Elbow for Hamm HD8 - HD10C (H170) Twin Drum Roller is a genuine Hamm component (OEM No. 1232541) designed to route fluid or air around a tight bend within the machine's system. Built from a robust metal alloy with a corrosion-resistant finish, this right‐angle elbow helps maintain reliable flow in demanding site conditions. It is engineered for direct replacement on Hamm compactors, offering a precise fit for models such as the HD8 and HD10C. By preserving sealed connections and preventing kinks or restrictions in pipework or hoses, it supports consistent system performance and reduces the risk of leaks. This part is suitable for routine maintenance or corrective repairs on twin drum rollers operating in heavy-duty environments.
Key Features:
- Genuine Hamm part for assured compatibility and reliability (OEM No. 1232541)
- Durable metal construction with corrosion resistance for long service life
- Right‐angle form factor to maintain smooth flow in confined spaces
- Direct-fit replacement to use existing mounts and routing paths
- Helps prevent leaks and pressure losses at tight bends
- Stable under vibration and shock typical of compaction work
- Suitable for hydraulic or pneumatic routing within the roller system
- Supports efficient operation and reduced unplanned downtime
- Designed for use in harsh construction environments
- Compatible with a wide range of Hamm twin drum roller models
Typical Applications:
Used to connect and turn fluid or air lines through a compact 90° path on Hamm twin drum rollers. Commonly fitted during hose or pipe replacements, leak rectification, or scheduled servicing to restore reliable flow. Suitable for routing in areas with limited clearance around engines, pumps, valves, or control manifolds where a straight connector would kink or stress the line.
Also known as:
Elbow connector, roller elbow, right‐angle fitting, hydraulic elbow, pneumatic elbow, elbow adaptor, pipe elbow, 90‐degree connector, angle union, elbow coupling.
Fits Models:
HD10-12, HD1012, HD10E-12E, HD10i-12i, HD13-14, HD1314, HD13i-14i, HD18-20, HD1820, HD30-35, HD3035, HD50, HD8-10C, HD810C
Product Specifications
| L&S Part No. | 1232541 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | HAMM |
| OEM No. | 1232541 |
| Unit of Sale | 1 |
| Applications | HD10-12, HD1012, HD10E-12E, HD10i-12i, HD13-14, HD1314, HD13i-14i, HD18-20, HD1820, HD30-35, HD3035, HD50, HD8-10C, HD810C |
| Machine Type | Rollers |
| Fits Models | HD8 - 10C (H170) Twin Drum Compaction Roller | HD13 - 14 (H172) Twin Drum Roller | HD10 - 12 (H171) Twin Drum Roller | HD10 - 12 (H230) | HD10 - 12 (H262) | HD10E - 12E (H289) | HD8 - 10C (H263) | HD30 - 35 (H247) | HD30 -35 (H286) | HD50 (H290) | HD50 (H295) | HD10i - 12i (H251) | HD13i - 14i (H231) | HD18 - 20 (H292) | HD18 - 20 (H293) |
