Description
Overview:
Dual purpose ball hitch with a pin through ball arrangement, allowing a 50mm ball coupling trailer or a pinned implement to be towed from one mounting. Two-bolt fixing to the towing plate. Rated at 1500kg with a D-value of 9.81kN, and is not type approved for road use.
Specification:
- D-value: 9.81kN
- Manufacturer rated capacity: 1500kg (equivalent to a 3,000kg towing vehicle)
- Ball diameter: 50mm
- Pin: 16mm diameter x 154mm long
- Mounting: 2 x M16 bolt holes
- Overall height: 120mm
- Plate width: 140mm
Towing Capacity:
Maximum braked trailer weight derived from the D-value:
- Behind a 3,500kg vehicle: 1,400kg
- Behind a 7,500kg vehicle: 1,150kg
These are coupling limits only. The lowest of the coupling limit, the towing vehicle's plated towing limit, the trailer's gross weight and the driver's licence entitlement applies. Centre-axle trailers are rated on Dc and V-value rather than D.
Typical Applications:
Agricultural and off-road use only, on tractors, yard loaders and farm equipment towing implements and trailers within the holding. Not for road use.
Product Specifications
| L&S Part No. | S4057 |
|---|---|
| Unit of Sale | 1 |
| Size | 50mm Ball |
| Machine Type | Tractors, Trailers |
| Key Features | - Ball diameter: 50mm - Pin: 16mm diameter, 154mm long - Load capacity: 1500kg - Two-bolt M16 mounting - For agricultural, off-road use only |
