Description
Overview:
This oval air filter is a non-genuine replacement designed to fit Yanmar L90AE and L100AE single-cylinder diesel engines used in construction and garden machinery. Built with a pleated paper media supported by a perforated steel core and finished with moulded rubber end caps, it provides reliable filtration while maintaining airflow. A removable foam pre-filter sleeve helps trap larger particles, extending service intervals and protecting the main element. It replaces OEM reference 114650-1259 and is identified by MPN A663. Approximate dimensions: length 150 mm, height 73 mm, width 98 mm, with an oval outer size around 142 mm x 98 mm and an inner size around 95 mm x 51 mm. Suitable as a direct replacement where the original filter specification is required.
Key Features:
- Non-genuine replacement matching the form and fit of OEM 114650-1259
- Pleated cellulose media for efficient fine dust capture and stable airflow
- Foam pre-filter sleeve to intercept larger debris and prolong element life
- Perforated steel support for strength and shape retention under load
- Moulded rubber end caps for a consistent seal in the air box
- Dimensions suited to common housings: 150 x 98 x 73 mm (L x W x H)
- Oval profile to suit compact engine compartments
- Helps maintain fuel efficiency and engine power by reducing intake restriction
- Quick to install with no modifications when replacing the like-for-like part
- Durable construction suitable for daily site and workshop use
Typical Applications:
Used on compact equipment driven by Yanmar L90AE and L100AE engines, including plate compactors, generators, pumps, trench rammers, light rollers, and small plant used on building sites, landscaping, and grounds maintenance. Also found on similar machinery from other manufacturers where the same air box specification is used. Ideal for routine servicing to protect against dust, sand, and chaff.
Also known as:
Air cleaner element, intake filter, primary air element, oval filter cartridge, pre-cleaner filter, engine intake cartridge, paper element with foam pre-filter, service filter, replacement filter element.
Fits Models:
186F, L100, L100AE, L90, L90AE, VT2, ACR 70 D, ADS 70, APF 1240, AVP 1240 DY, AVP 1240 2, AVP 1850 D, AVP 3510, PC 03 1, PC 03 2, YB 101, ACR70D, ADS70, APF1240, AVP1240DY, AVP12402, AVP1850D, AVP3510, PC031, PC032, YB101
Alternate Part Numbers:
114650.12540, 114650.12570, 114650.12590, 114650.12591, 11465012590, 114650.1259, 114650-1259, 114650-1254, 11465012540, 114650.1257, 114650-1257, 11465012570, 11465012591, 114650.1254, 1146501254, 1146501257, 1146501259, 029 0007, MD.5184, WGA1169, 5744134, FFA1146, 0290007, MD-5184, BSA2006
Product Specifications
| L&S Part No. | LA1376 |
|---|---|
| OEM No. | A663 |
| Unit of Sale | 1 |
| Size | Length: 150mm x Height: 73mm x Width: 98mm |
| Applications | 186F, L100, L100AE, L90, L90AE, VT2, ACR 70 D, ADS 70, APF 1240, AVP 1240 DY, AVP 1240 2, AVP 1850 D, AVP 3510, PC 03 1, PC 03 2, YB 101, ACR70D, ADS70, APF1240, AVP1240DY, AVP12402, AVP1850D, AVP3510, PC031, PC032, YB101 |
| Machine Type | Engines |
| Fits Brands | Alco Filters, Ammann, Bomag, Greyfriars, Komatsu, Sure, TFS, Wacker Neuson, Woodgate, Yanmar |
| Fits Models | L90AE | VT2 | L100AE |
