Description
Overview:
The Pan Head Screw M4x12 is a genuine Stihl OEM fastener designed to secure covers, housings, and assemblies across a wide range of Stihl equipment. Made from durable steel, it offers reliable clamping and a neat, low-profile finish thanks to its pan head design. This screw is commonly found in brushcutters and chainsaws, including models such as the FS200 and 015, where a precise M4 thread and 12 mm length are required for correct fit and function. Identified by MPN 9048 319 0660, it is engineered for consistency and long-term use in demanding environments. Its standard M4 sizing supports straightforward replacement during maintenance, helping to keep your machine operating smoothly and safely. Genuine Part.
Key Features:
- Genuine Stihl part for assured compatibility and performance
- Durable steel construction for dependable holding strength
- Pan head provides a wide bearing surface for secure seating and tidy finish
- Standard M4 thread for predictable, repeatable fit in specified locations
- Dimensions: M4 x 12 mm; approximately 0.16 in (4.06 mm) diameter x 0.47 in (11.94 mm) length
- Suited to frequent service tasks where components must be removed and refitted
- Supports correct alignment of covers and guards to protect internal parts
- OEM quality helps reduce loosening under vibration in outdoor power equipment
Typical Applications:
Used to fasten shrouds, handle frames, guards, and small sub-assemblies on Stihl brushcutters, chainsaws, and cut-off saws. Ideal for routine maintenance, part replacements, and repairs where an M4 x 12 mm pan head screw is specified. Suitable for environments with vibration and frequent on-site servicing.
Also known as:
Machine screw, M4 x 12 fixing, retaining screw, fastener, pan head bolt, M4x12 hardware, OEM screw for covers and housings.
Fits Models:
015, 020, 020T, 030, 031, 032, 041, 041AV, 041FB, 041G, 042 AV, 042AV, 045, 048, 050, 051, 056, 075, 08S, E10, E15, FS120, FS150, FS151, FS20, FS200, FS202, FS250, FS360C, FS410, FS410AV, FS410C, FS75, FS80, FS85, MS200, MS200T, MSE, TS08, TS08S, TS50, TS510, TS760
Alternate Part Numbers:
9048-319-0660, 90483190660
Product Specifications
| L&S Part No. | 9048 319 0660 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Stihl |
| OEM No. | 90483190660 |
| Unit of Sale | 1 |
| Machine Type | Brushcutters, Chainsaws, Disc Cutters |
| Fits Brands | Stihl |
| Key Features | - Genuine Stihl part ensures compatibility with specified models - Made from durable steel for reliable holding strength - Pan head design offers secure seating and tidy finish - Standard M4 x 12 mm dimensions for precise fit - Suitable for Stihl brushcutters and chainsaws, including FS200 and 015 models |
| Fits Models | MS200, MS200T | 030, 031 | 08S | TS510 | FS75, FS80, FS85 | FS120, FS200, FS250 | FS360C FS410C | TS08S, TS08 | TS50 | FS80 | FS150, FS151 | FS20 | FS200, FS202 | FS410AV (old model) | 015 | 020, 020T | 032 | 041 | 042 AV | 048 | 050, 051 | 056 | 075 | E15 | 045 | TS760 |
