Description
Overview:
This is a 145/80B10 trailer wheel and tyre assembly (MPN 211 005), supplied fitted with a Deli bias-ply tubeless tyre on a 10 inch (254 mm) silver rim. The tyre is 145 mm wide with an 80% aspect ratio, rated at 4PR and marked 74N, giving a load capacity of 375 kg per wheel and a speed rating up to N (87 mph / 140 km/h). The rim is coded 3.50Bx10H2, with zero offset (ET0) and a 66.7 mm centre bore. The hub fixing is 4 stud on a 4 inch (101.6 mm) PCD, a common pattern on many small and medium UK trailers using 10 inch wheels. Supplied as a complete wheel and tyre ready to fit, with the Deli S255 tread pattern and tubeless construction suited to general trailer use in transport, light plant and utility applications.
Key Features:
- Tyre size 145/80B10 bias-ply (145 mm width, 80% aspect ratio, 10 inch rim)
- Ply rating: 4PR (reinforced construction)
- Load index 74 = 375 kg per tyre; Speed rating N = 87 mph (140 km/h)
- Tubeless (TL) tyre for straightforward maintenance
- Tread pattern: Deli S255 for general trailer use
- Rim size: 3.50Bx10H2 (3.50 inch / 88.9 mm width, 10 inch / 254 mm diameter)
- Hub fixing: 4 stud on 4 inch PCD (101.6 mm) for common UK trailer hubs
- Centre bore: 66.7 mm
- Offset: 0 (ET0) for standard trailer hub alignment
- Rim finish: Silver
Typical Applications:
Suitable for small to medium trailers that use 10 inch wheels with a 4 stud, 4 inch (101.6 mm) PCD hub, including general purpose trailers, camping and utility trailers, light boat trailers, and site/plant support trailers. Used as an original fit or replacement assembly where a 145/80B10 tubeless bias tyre on a 3.50Bx10 rim, 0 offset and 66.7 mm centre bore is specified.
Also known as:
145/80-10 Bias Trailer Wheel and Tyre
10 Inch Trailer Wheel & Tyre 4PR TL, 4 Stud 4" PCD
145x10 Trailer Wheel Assembly, Silver Rim
Maypole part number MP21645
Product Specifications
| L&S Part No. | 211 005 |
|---|---|
| Part Type | Genuine Part |
| Unit of Sale | 1 |
| Key Features | - Tyre size 145/80B10, 145 mm width, 80% aspect ratio - Load index 74 supports 375 kg per tyre - Speed rating N allows up to 87 mph - 4 stud, 4 inch PCD hub for UK trailers - Zero offset (ET0) for standard hub alignment |
