Description
Overview:
The Pump Shim is a thin, precision steel spacer used to set and maintain correct fuel injection pump alignment on Yanmar single-cylinder L‐series diesel engines. This non-genuine part replaces OEM No. 114250-53400 and is suitable for workshop maintenance or field repairs where accurate pump positioning is required. Fitted between the pump base and the crankcase, it helps achieve the correct pump height and timing, supporting smooth starting and reliable running. Made from durable steel with a flat, stable profile, it is designed to seat cleanly without distortion when torqued. Ideal for compact construction and garden machinery powered by these engines, including generators, water pumps, plate compactors, and small agricultural equipment. Compatible with models such as Yanmar L40 and L100.
Key Features:
- Non-genuine replacement for Yanmar OEM 114250-53400
- Precision shim for accurate pump height and timing alignment
- Flat steel construction for stability and long service life
- Seats between the injection pump and crankcase for consistent positioning
- Helps correct misalignment after overhauls, gasket changes, or pump replacement
- Supports reliable starting and consistent engine operation when used correctly
- Suitable for Yanmar L‐series and common equivalent clone engines (170F/178F/186F)
- Clean-edged profile for true seating and repeatable assembly
- Practical, low-cost part for routine servicing and timing adjustments
- Supplied to match OEM fit and footprint for straightforward installation
- Manufacturer Part Number (MPN): 320 332
- Genuine status: Non Genuine Part
Typical Applications:
Used during injection pump servicing, engine rebuilds, or timing adjustments on small plant and garden machinery. Common on generators, water pumps, plate compactors, concrete equipment, tillers, and light agricultural machines powered by Yanmar L‐series engines or compatible equivalents. Helps maintain correct fuel delivery timing and alignment after component replacement or wear.
Also known as:
Injection pump shim, pump timing shim, adjustment shim, spacer plate, calibration shim, packer shim, setting shim, fuel pump spacer.
Fits Models:
170F, 178F, 186F, L100, L40, L40AE, L48, L60, L60AE, L70, L75, L90, L90AE
