Description
Overview:
This 3 x 6 pan screw is a small, precision-engineered fastener for Honda small petrol engines such as the GX120 and GX160. Made from durable steel with a corrosion-resistant finish, it is designed to secure light-duty engine components reliably under vibration and heat. The screw has an M3 thread and 6 mm length, suitable for covers, brackets, and housings found on compact engines used in construction and garden equipment. Dimensions: 3 mm x 6 mm (0.12 in x 0.24 in). Brand: Honda. Part number: 93500 03006 1H. It provides a neat, low-profile pan head for a clean fit where clearance is limited, helping keep assemblies properly tightened during service. Ideal for maintenance and replacement on small engines and compatible Honda lawn mowers.
Key Features:
- Steel pan head machine screw with corrosion-resistant finish for long service life
- M3 x 6 mm size for light-duty engine and equipment fittings (3 mm x 6 mm / 0.12 in x 0.24 in)
- Accurate thread and head profile for consistent drive engagement and torque
- Low-profile pan head suits shrouds, guards, covers, and small brackets
- Suitable for high-vibration environments common to compact petrol engines
- Compatible with a wide range of Honda GX-series engines and selected HRH536 mowers
- Easy to fit with standard cross-recess driver; helps prevent loosening when correctly torqued
- Useful as a like-for-like service replacement to maintain original assembly specifications
Typical Applications:
Commonly used to fasten blower housings, recoil starter covers, air filter housings, cable clips, and small brackets on Honda GX engines and professional HRH536 mowers. Suitable for compactors, generators, pressure washers, water pumps, and lawn machinery where these engines are installed. Ideal for routine servicing, repairs, and replacing missing or damaged screws.
Also known as:
Pan head machine screw, M3 x 6 fastener, cross-recess engine screw, pan head bolt, small engine screw, cover screw, shroud screw, Honda engine fastener.
Fits Models:
GX100, GX100U, GX120, GX120K1, GX120T1, GX120T2, GX120U1, GX120UT1, GX120UT2, GX160, GX160H1, GX160K1, GX160T1, GX160T2, GX160U1, GX200, GX240, GX270, GX270T, GX270U, GX270UT, GX340K1, GX340T1, GX340T2, GX340U1, GX340UT1, GX390H1, GX390K1, GX390T1, GX390T2, GX390UT1, HRH536 HXE, HRH536HXE, HRH536K1 HXE, HRH536K1 QXE, HRH536K1HXE, HRH536K1QXE, HRH536K2 HXE, HRH536K2 QXE, HRH536K2HXE, HRH536K2QXE, HRH536K3 HXE, HRH536K3 QXE, HRH536K3HXE, HRH536K3QXE, HRH536K4 HXEH, HRH536K4 QXEH, HRH536K4HXEH, HRH536K4QXEH
Product Specifications
| L&S Part No. | 93500 03006 1H |
|---|---|
| Manufacturer | Honda |
| OEM No. | 93500030060 |
| Unit of Sale | 1 |
| Machine Type | Engines, Mowers |
| Fits Brands | Honda |
| Key Features | - M3 x 6 mm size for light-duty engine fittings - Steel with corrosion-resistant finish for durability - Compatible with Honda GX-series engines and HRH536 mowers - Low-profile pan head for limited clearance areas - Suitable for high-vibration environments in compact engines |
| Fits Models | GX100 (GCANM) | GX100U (GCAGK) | GX120K1 (GC01) | GX340K1 (GC05) | GX120T1 (GCAAT) | GX120UT1 (GCAGT) | GX340U1 (GCAMK) | GX120U1 (GCAHK) | GX340UT1 (GCAVT) | GX120UT2 (GCBMT) | GX340T1 (GCAWT) | GX120T2 (GCBNT) | GX160K1 (GC02) | GX340T2 (GCBFT) | GX160H1 (GCAAH) | GX340K1 (GDAE) | GX160K1 (GCAAK) | GX160T1 (GCABT) | GX160U1 (GCACK) | GX160T2 (GCBRT) | GX270T (GCADT) | GX270UT (GCAJT) | GX270U (GCALK) | GX390K1 (GDAF) | GX390T1 (GCAET) | GX390H1 (GCAFH) | GX390UT1 (GCAKT) | GX390T2 (GCBDT) | GX390K1 (GCAA) | HRH536 HXE | HRH536K1 HXE | HRH536K1 QXE | HRH536K2 HXE | HRH536K2 QXE | HRH536K3 HXE | HRH536K3 QXE | HRH536K4 HXEH | HRH536K4 QXEH |
