Description
Overview:
This Genuine Stihl spline screw is a steel fixing with an internal spline drive, sized M5 x 30 mm (1.18 in). It is used to secure components on a wide range of Stihl machines, ensuring a precise fit and reliable clamping. Designed for demanding outdoor and construction environments, the black‐coated steel resists wear and helps protect against corrosion. Ideal for service and repairs on cut-off saws such as the TS410 and TS420, as well as many Stihl brushcutters, hedge trimmers, augers and other power tools. OEM Part No. 9022 341 1070. A direct replacement that restores correct fastening where the original fixing is worn, missing or damaged, helping to maintain safe, stable assemblies.
Key Features:
- Genuine Stihl part for assured fit and performance (OEM 9022 341 1070)
- M5 thread, 30 mm length (1.18 in) for common chassis and cover fixings
- Internal spline drive for positive engagement and reduced cam‐out
- Durable steel construction with black protective finish
- Helps maintain secure assemblies under vibration and load
- Suitable for repeated removal/refit during servicing
- Compatible across a large range of Stihl tools for simplified spares stock
- Replaces worn or lost fasteners to restore equipment integrity
Typical Applications:
General fastening on Stihl machines, including covers, housings, guards, handles and ancillary fittings. Common in routine maintenance, rebuilds and component replacement on cut-off saws, brushcutters, hedge trimmers, long‐reach trimmers, earth augers and similar professional and domestic equipment.
Also known as:
Spline-drive screw, spline-head fixing, M5 machine screw, M5 x 30 fastener, retaining screw, service screw, chassis screw.
Fits Models:
044, 046, 050, 051, 076, BR106, BT 120 C, BT 121, BT 121 Z, BT 130, BT 130 Z, BT 131, BT 360, BT106, BT120C, BT121, BT121Z, BT130, BT130Z, BT131, BT360, FR106, FR108, FR125, FR135, FR145, FS106, FS108, FS160, FS180, FS220, FS220K, FS280, FS280K, FS290, FS36, FS360, FS360C, FS40, FS410C, FS420, FS420L, FS44, FS50, FS500, FS55, FS550, FS550L, FS55C, FS55R, FS55RC, FS55T, FS62, FS66, FS72, FS74, FS75, FS76, FS80, FS81, FS85, FS86, FS88, FSA120R, HL 95, HL 95 K, HL100, HL100K, HL90, HL90K, HL95, HL95K, HS72, HS74, HS75, HS76, HS81, HS81R, HS81RC, HS81T, HS81TC, HS82, HS85, HS86, HS86R, HS86T, HS87, HSA100, HSA130R, HSA130T, HSA60, HSA94, HT70, HT70K, HT75, HTA 135, HTA135, KA85R Attachment, KA85RAttachment, MS440, MS460, SP81, SP90, TS350, TS360, TS400, TS410, TS420, TS440, TS460, TS480i, TS500i, TS510, TS700, TS760
Alternate Part Numbers:
9022-341-1070, 90223411070
Product Specifications
| L&S Part No. | 9022 341 1070 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Stihl |
| OEM No. | 90223411070 |
| Unit of Sale | 1 |
| Size | IS-M5 x 30mm |
| Applications | 044, 046, 050, 051, 076, BR106, BT 120 C, BT 121, BT 121 Z, BT 130, BT 130 Z, BT 131, BT 360, BT106, BT120C, BT121, BT121Z, BT130, BT130Z, BT131, BT360, FR106, FR108, FR125, FR135, FR145, FS106, FS108, FS160, FS180, FS220, FS220K, FS280, FS280K, FS290, FS36, FS360, FS360C, FS40, FS410C, FS420, FS420L, FS44, FS50, FS500, FS55, FS550, FS550L, FS55C, FS55R, FS55RC, FS55T, FS62, FS66, FS72, FS74, FS75, FS76, FS80, FS81, FS85, FS86, FS88, FSA120R, HL 95, HL 95 K, HL100, HL100K, HL90, HL90K, HL95, HL95K, HS72, HS74, HS75, HS76, HS81, HS81R, HS81RC, HS81T, HS81TC, HS82, HS85, HS86, HS86R, HS86T, HS87, HSA100, HSA130R, HSA130T, HSA60, HSA94, HT70, HT70K, HT75, HTA 135, HTA135, KA85R Attachment, KA85RAttachment, MS440, MS460, SP81, SP90, TS350, TS360, TS400, TS410, TS420, TS440, TS460, TS480i, TS500i, TS510, TS700, TS760 |
| Machine Type | Disc Cutters, Hedgetrimmers, Brushcutters |
| Fits Brands | Stihl |
| Fits Models | TS400 | TS410, TS420 | TS350, TS360 | MS440 | MS460 | TS700 | TS510 | TS460 | FS36, FS40, FS44 | FS40, FS50 | FS55, FS55C, FS55R | FS75, FS80, FS85 | FS220, FS280, FS290 | FS360C FS410C | FS500, FS550, FS550L | TS440 | TS480i, TS500i | HS72, HS74, HS76 | HS75 | HS81, HS86 | HS82 | HSA94 | BR106 | FS62, FS66 | FS72, FS74, FS76 | FS81, FS86 | FS88 | FS106 | FS108 | FS160, FS180 | FS360, FS420, FS420L (older models) | FR106 | FR125, FR135, FR145 | FR108 | 044 | 046 | 050, 051 | 076 | HT70, HT70K, HT75 | KA85R Attachment | BT 130 | BT 131 | BT 360 | BT 120 C | BT 121 | BT 121 Z | BT 130 Z | HL90K, HL90, HL95K | HL100, HL100K | HS85 | HS87 | HL 95, HL 95 K | HSA130R, HSA130T | HSA60 | HSA100 | FSA120R | HTA 135 | TS710i | FSA70R | FSA80R | TS760 | HT134 | KMA80R | KMA120R | KMA200R | HSA140 | HSA150 | FSA80 | FSA200R |
