Description
Overview:
This Genuine Husqvarna bracket (OEM No. 506 86 96-01) is a heavy-duty mounting and support component for Husqvarna Rider mowers. Made from robust, formed steel with a protective finish, it is designed to support and stabilise the cutting deck under load, helping to maintain a consistent cutting height and smooth operation. It is a direct-fit replacement for worn or bent hardware on a wide range of machines, including the R13 C5 and R214T AWD. By restoring the correct deck position and alignment, this bracket helps reduce vibration and ensures reliable performance across lawns, paddocks, and rougher ground typical of UK conditions.
Key Features:
- Genuine Husqvarna part for assured compatibility and build quality
- OEM reference: 506 86 96-01 (also 506869601) for accurate identification
- Durable steel construction for long service life in demanding use
- Supports and stabilises the cutting deck to maintain even cutting results
- Precise mounting geometry for a straight swap with the original bracket
- Helps minimise deck vibration and misalignment during mowing
- Fits a wide range of Rider models to simplify fleet maintenance
- Easy to install using standard workshop tools and existing fixings
Typical Applications:
Used to replace a bent, cracked, or corroded deck support on Husqvarna Rider mowers. Ideal when the cutting deck sits unevenly, vibrates, or drifts out of alignment, especially after impact or extended use on rough ground, banks, or around obstacles. Suitable for routine refurbishment to restore reliable deck stability.
Also known as:
Deck holder, deck hanger, deck mount, deck bracket, stabiliser bracket, support bracket, frame-to-deck bracket, rider deck stay, mower deck support.
Fits Models:
COMBI94, Combi 94, Combi 103, Combi 112, P524, P524EFI, PR14, PR15, PR17, PR17 AWD, PR18, PR18 AWD, Proflex 1200, Proflex 18, Proflex 20, Proflex 21, Proflex 21 AWD, R13 C5, R200-series Rider, R213 C, R214 TC, R214T AWD, R215 TX, R216 AWD, R300-series Rider, R316 T, R316 T AWD, R316 Ts AWD, R316 TXs AWD, R318, R320 AWD, R322T AWD, R418 Ts, R418 Ts AWD, R422 Ts, RC 318T, RC320Ts AWD, Rider 1030, Rider 11 BIO, Rider 11 C, Rider 11 R, Rider 1200, Rider 13 BIO, Rider 13 C, Rider 13 R, Rider 13 AWD, Rider 15 C, Rider 15 T, Rider 15 T AWD, Rider 155, Rider 155 AWD, Rider 15V2, Rider 15V2 AWD, Rider 16, Rider 16 C, Rider 16 C AWD, Rider 16 H, Rider 175, Rider 175 AWD, Rider 18, Rider 18 AWD, Rider PRO 18, RC318T, RC 320Ts AWD, SD48 Rider.
Alternate Part Numbers:
506 86 96-01, 506869601
Product Specifications
| L&S Part No. | 506 86 96 01 |
|---|---|
| Part Type | Genuine Part |
| Manufacturer | Husqvarna |
| OEM No. | 506869601 |
| Unit of Sale | 1 |
| Applications | COMBI94, Combi 103, Combi 112, Combi 94, Cutting Deck, P 524EFI Rider, P524, P524 Rider, P524EFI, PR14, PR14 Rider, PR15, PR15 Rider, PR17, PR17 AWD, PR17 AWD Rider, PR17 Rider, PR17AWD, PR18, PR18 AWD, PR18 AWD Rider, PR18 Rider, PR18AWD, Proflex 1200, Proflex 1200 Rider, Proflex 18, Proflex 18 Rider, Proflex 20, Proflex 20 Rider, Proflex 21, Proflex 21 AWD, Proflex 21 AWD Rider, Proflex 21 Rider, Proflex 21AWD, R13 C5, R13 C5 Rider, R13C5, R200-series Rider, R213 C, R213 C Rider, R213C, R214 T AWD Rider, R214 TC, R214 TC Rider, R214T AWD, R214TAWD, R214TC, R215 TX, R215 TX Rider, R215TX, R216 AWD, R216 AWD Rider, R216AWD, R300-series Rider, R316 T, R316 T AWD, R316 T AWD Rider, R316 T Rider, R316 TXs AWD, R316 TXs AWD Rider, R316 Ts AWD, R316 Ts AWD Rider, R316T, R316TAWD, R316TXsAWD, R316TsAWD, R318, R318 Rider, R320 AWD, R320 AWD Rider, R320AWD, R322T AWD, R322T AWD Rider, R322TAWD, R418 TS AWD Rider, R418 Ts, R418 Ts AWD, R418 Ts Rider, R418Ts, R418TsAWD, R422 Ts, R422 Ts AWD Rider, R422 Ts Rider, R422Ts, RC 318T, RC 318T Rider, RC 320Ts AWD Rider, RC318T, RC320Ts AWD, RC320TsAWD, RIDER16, RIDER18, Rider 1030, Rider 11 BIO, Rider 11 C, Rider 11 R, Rider 11BIO, Rider 11C, Rider 11R, Rider 1200, Rider 13 AWD, Rider 13 BIO, Rider 13 C, Rider 13 R, Rider 13AWD, Rider 13BIO, Rider 13C, Rider 13R, Rider 15 C, Rider 15 T, Rider 15 T AWD, Rider 155, Rider 155 AWD, Rider 155AWD, Rider 15C, Rider 15T, Rider 15TAWD, Rider 15V2, Rider 15V2 AWD, Rider 15V2AWD, Rider 16, Rider 16 C, Rider 16 C AWD, Rider 16 H, Rider 16C, Rider 16CAWD, Rider 16H, Rider 175, Rider 175 AWD, Rider 175AWD, Rider 18, Rider 18 AWD, Rider 18AWD, Rider PRO 18, Rider PRO18, SD48 Rider |
| Machine Type | Lawn Tractors |
| Fits Brands | Husqvarna |
| Fits Models | SD48 | Combi 103 | Combi 103 | Combi 112 | Combi 94 | Combi 94 | P 524EFI Rider | P524 Rider | PR14 Rider | PR15 Rider | PR17 Rider | PR17 AWD Rider | PR18 Rider | PR18 AWD Rider | PROFLEX 1200 Rider | PROFLEX 18 Rider | PROFLEX 20 Rider | PROFLEX 21 Rider | PROFLEX 21 AWD Rider | R13 C5 Rider | R213 C Rider | R214 T AWD Rider | R214 TC Rider | R215 TX Rider | R216 AWD Rider | R316 T Rider | R316 T AWD Rider | R316 Ts AWD Rider | R316 TXs AWD Rider | R318 Rider | R320 AWD Rider | R322T AWD Rider | R418 Ts Rider | R418 TS AWD Rider | R422 Ts Rider | R422 Ts AWD Rider | RC 318T Rider | RC 320Ts AWD Rider | RIDER 1030 | RIDER 11 BIO | RIDER 11 C | RIDER 11 R | RIDER 1200 | RIDER 13 AWD | RIDER 13 BIO | RIDER 13 C | RIDER 13 R | RIDER 15 C | RIDER 15 T | RIDER 15 T AWD | RIDER 155 | RIDER 155 AWD | RIDER 15V2 | RIDER 15V2 AWD | RIDER 16 | RIDER 16 C | RIDER 16 C AWD | RIDER 16 H | RIDER 175 | RIDER 175 AWD | RIDER 18 | RIDER 18 AWD | RIDER PRO 18 |
